FOTEK SU-07W SU Series U-Type Mark Photo Sensor, White LED
- Brand
- FOTEK
- Model
- SU-07W
- GEARWELL SKU
- GWP-000023644
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Type
- Thru beam type (U-type mark sensor)
- Output
- NPN & PNP two outputs, 150 mA max.; standard NO (-B: NC)
- Emitter
- white LED
- Connection
- cable, 2 m
- Protection
- IP-65
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FOTEK SU-07W SU Series U-Type Mark Photo Sensor, White LED |
|---|---|
| Brand | FOTEK |
| Model | SU-07W |
| Category | Proximity & Photoelectric Sensors |
| Type | Thru beam type (U-type mark sensor) |
| Output | NPN & PNP two outputs, 150 mA max.; standard NO (-B: NC) |
| Emitter | white LED |
| Connection | cable, 2 m |
| Protection | IP-65 |
| Sensible object | transparent object, min. 2.0 mm |
| Operating voltage | 10-30 VDC, ripple < 20 % |
| Response frequency | 1 kHz |
| Current consumption | 30 mA max. |
