FOTEK MY-6S-2P-24VDC MY Series Mini On-Delay Timer
- Brand
- FOTEK
- Model
- MY-6S-2P-24VDC
- GEARWELL SKU
- GWP-000021103
- Category
- PLCs & I/O
Key specifications
- Output
- 2P relay
- Dimension
- 22.0 x 28.5 mm
- Model key
- MY-□□-□P-□□□V
- Time range
- 6S (single range)
- Contact rating
- 7 A / 250 VAC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FOTEK MY-6S-2P-24VDC MY Series Mini On-Delay Timer |
|---|---|
| Brand | FOTEK |
| Model | MY-6S-2P-24VDC |
| Category | PLCs & I/O |
| Output | 2P relay |
| Dimension | 22.0 x 28.5 mm |
| Model key | MY-□□-□P-□□□V |
| Time range | 6S (single range) |
| Contact rating | 7 A / 250 VAC |
| Supply voltage | 24 VDC |
| Repeat accuracy | 0.2% of F.S. max. |
| Setting accuracy | 5% of F.S. max. |
| Operating ambient | -20 ~ +60 °C, 35 ~ 85% RH |
| Power consumption | 3 VA max. |
