FOTEK NT-20V NT Series PID Temperature Controller
- Brand
- FOTEK
- Model
- NT-20V
- GEARWELL SKU
- GWP-000021105
- Category
- Pressure, Flow & Temperature
Key specifications
- Input
- PT/K/J/R/S/T/B/E/N/L selectable
- Outline
- 48x96x60 mm
- Alarm output
- two alarms, relay 1a (3 A/250 VAC)
- Control method
- Fuzzy + PID or ON/OFF selectable
- Control output
- voltage pulse (SSR drive)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FOTEK NT-20V NT Series PID Temperature Controller |
|---|---|
| Brand | FOTEK |
| Model | NT-20V |
| Category | Pressure, Flow & Temperature |
| Input | PT/K/J/R/S/T/B/E/N/L selectable |
| Outline | 48x96x60 mm |
| Alarm output | two alarms, relay 1a (3 A/250 VAC) |
| Control method | Fuzzy + PID or ON/OFF selectable |
| Control output | voltage pulse (SSR drive) |
| Display accuracy | ±(0.1% F.S. + 1 digit) |
| Operating ambient | -25~80 °C; 35~85% RH |
| Power supply options | 90~265 VAC 50/60 Hz or 24 VDC/AC (specify on order) |
| Display / setting range | -999~9999 |
