FOTEK MT96-L MT Series PID Temperature Controller
- Brand
- FOTEK
- Model
- MT96-L
- GEARWELL SKU
- GWP-000022732
- Category
- Pressure, Flow & Temperature
Key specifications
- Dimension
- 96x96x80 mm
- Alarm output
- 3A/250VAC SPDT
- Power supply
- 90-265 VAC 50/60 Hz
- Sensor input
- K / J / PT-100 selectable
- Control method
- Fuzzy + PID or ON/OFF settable
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FOTEK MT96-L MT Series PID Temperature Controller |
|---|---|
| Brand | FOTEK |
| Model | MT96-L |
| Category | Pressure, Flow & Temperature |
| Dimension | 96x96x80 mm |
| Alarm output | 3A/250VAC SPDT |
| Power supply | 90-265 VAC 50/60 Hz |
| Sensor input | K / J / PT-100 selectable |
| Control method | Fuzzy + PID or ON/OFF settable |
| Control output | Linear 4-20 mA, load 600 Ω max |
| Display accuracy | ±0.1% of FS + 1 digit |
