FOTEK DSC-465 DSC Series Single-Phase Digital Power Regulator (SCR)

Key specifications

Input: 4~20 mA / 0~20 mA / 1~5 V / 2~10 V / 0~5 V / 0~10 V / VR 10 kΩ selectable
Cooling fan: 60x60 12 VDC
Output range: 0~100 %
Rated current: 65 A max.
Surge current: 1500 A / 1 cycle

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	FOTEK DSC-465 DSC Series Single-Phase Digital Power Regulator (SCR)
Brand	FOTEK
Model	DSC-465
Category	Contactors & Starters
Input	4~20 mA / 0~20 mA / 1~5 V / 2~10 V / 0~5 V / 0~10 V / VR 10 kΩ selectable
Cooling fan	60x60 12 VDC
Output range	0~100 %
Rated current	65 A max.
Surge current	1500 A / 1 cycle
Control method	zero-cross or phase-angle control selectable
Protection fuse	80 A semiconductor fuse inside
Operating voltage	440 VAC
Operating temperature	-20~80 °C; 35~85% RH
