FOTEK CDR-60X M18 Reflex Type Photoelectric Sensor, 60 cm
- Brand
- FOTEK
- Model
- CDR-60X
- GEARWELL SKU
- GWP-000023632
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Type
- Reflex type
- Connection
- lead wire, 4 cores, 5.0 mm dia. x 2 m
- Output method
- NPN & PNP
- Response time
- 2 ms
- Output current
- 150 mA max.
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FOTEK CDR-60X M18 Reflex Type Photoelectric Sensor, 60 cm |
|---|---|
| Brand | FOTEK |
| Model | CDR-60X |
| Category | Proximity & Photoelectric Sensors |
| Type | Reflex type |
| Connection | lead wire, 4 cores, 5.0 mm dia. x 2 m |
| Output method | NPN & PNP |
| Response time | 2 ms |
| Output current | 150 mA max. |
| Protection class | IP-66 |
| Sensing distance | 60 cm |
| Sensitivity adjuster | 270° trimmer |
| Operating temperature | -20 to +60 °C |
| Operating voltage (DC type) | 10-30 VDC, ripple < 20 % |
