FESTO 156860 ADVUL-20-15-P-A Compact Cylinder
- Brand
- FESTO
- Model
- 156860
- GEARWELL SKU
- GWP-000023650
- Category
- Cylinders & Actuators
Key specifications
- Stroke
- 15 mm
- Part number
- 156860
- Piston diameter
- 20 mm
- Type designation
- ADVUL-20-15-P-A
- Mode of operation
- Double-acting
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FESTO 156860 ADVUL-20-15-P-A Compact Cylinder |
|---|---|
| Brand | FESTO |
| Model | 156860 |
| Category | Cylinders & Actuators |
| Stroke | 15 mm |
| Part number | 156860 |
| Piston diameter | 20 mm |
| Type designation | ADVUL-20-15-P-A |
| Mode of operation | Double-acting |
| Operating pressure | 1 ... 10 bar |
| Ambient temperature | -20 ... 80 °C |
| Pneumatic connection | M5 |
| Impact energy in the end positions | 0.14 J |
| Theoretical force at 6 bar, advancing | 188 N |
