FESTO 170686 FRM-D-MAXI Branching Module
- Brand
- FESTO
- Model
- 170686
- GEARWELL SKU
- GWP-000023651
- Category
- Air Preparation
Key specifications
- Part number
- 170686
- Product weight
- 442 g
- Type designation
- FRM-D-MAXI
- Operating pressure
- 0 ... 16 bar
- Ambient temperature
- -10 ... 60 °C
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FESTO 170686 FRM-D-MAXI Branching Module |
|---|---|
| Brand | FESTO |
| Model | 170686 |
| Category | Air Preparation |
| Part number | 170686 |
| Product weight | 442 g |
| Type designation | FRM-D-MAXI |
| Operating pressure | 0 ... 16 bar |
| Ambient temperature | -10 ... 60 °C |
| Storage temperature | -10 ... 60 °C |
| Temperature of medium | -10 ... 60 °C |
| Festo lifecycle status | Phase-out |
| Pneumatic connection 3 | G3/4 |
| Air quality class at the output | Compressed air as per ISO 8573-1:2010 [7:-:-]; Inert gases |
| Standard nominal flow rate in main flow direction 1 -> 2 | 20000 l/min |
