FESTO 156001 ADVU-16 Compact Cylinder
- Brand
- FESTO
- Model
- 156001
- GEARWELL SKU
- GWP-000023649
- Category
- Cylinders & Actuators
Key specifications
- Part number
- 156001
- Stroke options
- 1 ... 200 mm (specify on order)
- Piston diameter
- 16 mm
- Type designation
- ADVU-16-...-P-A
- Mode of operation
- Double-acting
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FESTO 156001 ADVU-16 Compact Cylinder |
|---|---|
| Brand | FESTO |
| Model | 156001 |
| Category | Cylinders & Actuators |
| Part number | 156001 |
| Stroke options | 1 ... 200 mm (specify on order) |
| Piston diameter | 16 mm |
| Type designation | ADVU-16-...-P-A |
| Mode of operation | Double-acting |
| Operating pressure | 1.2 ... 10 bar |
| Ambient temperature | -20 ... 80 °C |
| Pneumatic connection | M5 |
| Configuration in seller title | ADVU-16-70-P-A (as collected; not verified) |
| Impact energy in the end positions | 0.1 J |
| Theoretical force at 6 bar, advancing | 121 N |
