FESTO 153319 QSM-M7-4-I Push-In Fitting
- Brand
- FESTO
- Model
- 153319
- GEARWELL SKU
- GWP-000023648
- Category
- Fittings, Tubing & Vacuum
Key specifications
- Size
- Mini
- Part number
- 153319
- Nominal width
- 3.1 mm
- Product weight
- 6 g
- Type designation
- QSM-M7-4-I
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FESTO 153319 QSM-M7-4-I Push-In Fitting |
|---|---|
| Brand | FESTO |
| Model | 153319 |
| Category | Fittings, Tubing & Vacuum |
| Size | Mini |
| Part number | 153319 |
| Nominal width | 3.1 mm |
| Product weight | 6 g |
| Type designation | QSM-M7-4-I |
| Ambient temperature | -10 ... 80 °C |
| Pneumatic connection 1 | External thread M7 |
| Pneumatic connection 2 | for pneumatic tubing outside diameter 4 mm |
| Tubing insertion depth | 11.5 mm |
| Type of seal on screwed plug | Sealing ring |
