Endress+Hauser PMD75-AAA7BB1BAAU Differential Pressure Transmitter
- Brand
- Endress+Hauser
- Model
- PMD75-AAA7BB1BAAU
- GEARWELL SKU
- GWP-000021499
- Category
- Pressure, Flow & Temperature
Key specifications
- Order code
- PMD75-AAA7BB1BAAU
- Communication
- 4...20 mA HART / PROFIBUS PA / FOUNDATION Fieldbus
- Reference accuracy
- Standard 0.05% / Platinum up to 0.035%
- Measuring principle
- Differential pressure, piezoresistive sensor with welded metallic membrane
- Process temperature
- -40...85 °C
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Endress+Hauser PMD75-AAA7BB1BAAU Differential Pressure Transmitter |
|---|---|
| Brand | Endress+Hauser |
| Model | PMD75-AAA7BB1BAAU |
| Category | Pressure, Flow & Temperature |
| Order code | PMD75-AAA7BB1BAAU |
| Communication | 4...20 mA HART / PROFIBUS PA / FOUNDATION Fieldbus |
| Reference accuracy | Standard 0.05% / Platinum up to 0.035% |
| Measuring principle | Differential pressure, piezoresistive sensor with welded metallic membrane |
| Process temperature | -40...85 °C |
| Measuring cell range | 10 mbar...250 bar (0.15...3750 psi) |
| Code suffix "AAA7BB1BAAU" | as collected; order-code positions not decoded (official ordering table not opened) |
| Max. overpressure limit (one side) | 420 bar |
| Supply voltage (4...20 mA HART, non-Ex) | 10.5...45 V DC |
