EATON XV-440-10TVB-1-10 XV400 10.4" Touch Panel HMI-PLC
- Brand
- EATON
- Model
- XV-440-10TVB-1-10
- GEARWELL SKU
- GWP-000017448
- Category
- HMIs & Industrial PCs
Key specifications
- Display
- Colour TFT, VGA 640 x 480, infra-red touch
- Evidence
- EATON datasheet XV-440-10TVB-1-10 (EATON Data Sheet Engine, 2021) (hosted at adegis.com)
- Processor
- RISC CPU, 32 bit, 400 MHz; 64 MB DRAM
- Catalog number
- 139904
- Screen diagonal
- 10.4 in
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | EATON XV-440-10TVB-1-10 XV400 10.4" Touch Panel HMI-PLC |
|---|---|
| Brand | EATON |
| Model | XV-440-10TVB-1-10 |
| Category | HMIs & Industrial PCs |
| Display | Colour TFT, VGA 640 x 480, infra-red touch |
| Evidence | EATON datasheet XV-440-10TVB-1-10 (EATON Data Sheet Engine, 2021) (hosted at adegis.com) |
| Processor | RISC CPU, 32 bit, 400 MHz; 64 MB DRAM |
| Catalog number | 139904 |
| Screen diagonal | 10.4 in |
| Operating system | Windows CE (licence required), CompactFlash card required |
| Power consumption | 15 typical / 26 max W |
| Built-in interfaces | 1 x Ethernet 100Base-TX/10Base-T, 1 x RS232, 1 x CAN, 2 x USB host, 1 x USB device |
| Degree of protection | IP65 front / IP20 rear |
| Rated operational voltage | 24 V DC (-15/+20%) |
