E+E Elektronik EE10-M1A6D1 EE10 Room Humidity/Temperature Sensor
- Brand
- E+E Elektronik
- Model
- EE10-M1A6D1
- GEARWELL SKU
- GWP-000022719
- Category
- Pressure, Flow & Temperature
Key specifications
- Status
- EE10 product page now redirects to successor HTS201 (discontinued); datasheet v3.3 still on epluse.com
- Display
- With display (D1)
- Model (M1)
- RH + T
- Enclosure
- EU standard (RAL9003 / RAL7035), 85 x 100 x 26 mm
- Output (A6)
- 4-20 mA (2-wire)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | E+E Elektronik EE10-M1A6D1 EE10 Room Humidity/Temperature Sensor |
|---|---|
| Brand | E+E Elektronik |
| Model | EE10-M1A6D1 |
| Category | Pressure, Flow & Temperature |
| Status | EE10 product page now redirects to successor HTS201 (discontinued); datasheet v3.3 still on epluse.com |
| Display | With display (D1) |
| Model (M1) | RH + T |
| Enclosure | EU standard (RAL9003 / RAL7035), 85 x 100 x 26 mm |
| Output (A6) | 4-20 mA (2-wire) |
| Order code | EE10-M1A6D1 |
| Supply voltage | 10 + 0.02 x RL < UV < 28 V DC |
| RH working range | 0...95 % RH |
| Protection rating | IP30 |
| RH accuracy (analogue) | ±2 % RH (40...60 % RH), ±3 % RH (10...90 % RH) |
