E+E Elektronik EE16-FT3B53 EE16 Duct Humidity/Temperature Transmitter
- Brand
- E+E Elektronik
- Model
- EE16-FT3B53
- GEARWELL SKU
- GWP-000022720
- Category
- Pressure, Flow & Temperature
Key specifications
- Filter (3)
- Sintered stainless steel filter
- Model (FT)
- Humidity + temperature
- Output (3)
- 0-10 V
- Housing (B)
- Duct mounting
- Order code
- EE16-FT3B53
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | E+E Elektronik EE16-FT3B53 EE16 Duct Humidity/Temperature Transmitter |
|---|---|
| Brand | E+E Elektronik |
| Model | EE16-FT3B53 |
| Category | Pressure, Flow & Temperature |
| Filter (3) | Sintered stainless steel filter |
| Model (FT) | Humidity + temperature |
| Output (3) | 0-10 V |
| Housing (B) | Duct mounting |
| Order code | EE16-FT3B53 |
| Supply (0-10 V) | 15-35 V DC or 24 V AC ±20 % |
| Probe length (5) | 200 mm |
| T output range | 0...50 °C |
| Housing / protection | Polycarbonate / IP65, NEMA 4 |
| RH accuracy at 20 °C | ±3 % RH |
