E+E Elektronik HTS201-M1A3 HTS201 Room Humidity/Temperature Sensor
- Brand
- E+E Elektronik
- Model
- HTS201-M1A3
- GEARWELL SKU
- GWP-000022724
- Category
- Pressure, Flow & Temperature
Key specifications
- Design
- EU format
- Display
- Without display
- Model (M1)
- RH + T
- Output (A3)
- 0-10 V
- Order code
- HTS201-M1A3
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | E+E Elektronik HTS201-M1A3 HTS201 Room Humidity/Temperature Sensor |
|---|---|
| Brand | E+E Elektronik |
| Model | HTS201-M1A3 |
| Category | Pressure, Flow & Temperature |
| Design | EU format |
| Display | Without display |
| Model (M1) | RH + T |
| Output (A3) | 0-10 V |
| Order code | HTS201-M1A3 |
| RH accuracy | ±(2 + 0.003 x mv) %RH |
| Supply voltage | 15-35 V DC or 24 V AC ±20 % |
| T accuracy (0-10 V) | ±0.25 °C |
| T measuring range | -30...+60 °C |
| RH measuring range | 0...100 %RH non-condensing |
