DELTA ECMC-EW1820SS ECMC series (ASDA-A3) AC Servo Motor
- Brand
- DELTA
- Model
- ECMC-EW1820SS
- GEARWELL SKU
- GWP-000029830
- Category
- Servo Systems
Key specifications
- Model code
- E=220V/2000r/min, W=22-bit absolute encoder, 18=180mm, 20=2kW, S=keyway with screw hole, brake and oil seal, S=standard shaft
- Rated speed
- 2000 r/min
- Rated torque
- 9.55 N-m
- Maximum speed
- 3000 r/min
- Rated current
- 11.2 Arms
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELTA ECMC-EW1820SS ECMC series (ASDA-A3) AC Servo Motor |
|---|---|
| Brand | DELTA |
| Model | ECMC-EW1820SS |
| Category | Servo Systems |
| Model code | E=220V/2000r/min, W=22-bit absolute encoder, 18=180mm, 20=2kW, S=keyway with screw hole, brake and oil seal, S=standard shaft |
| Rated speed | 2000 r/min |
| Rated torque | 9.55 N-m |
| Maximum speed | 3000 r/min |
| Rated current | 11.2 Arms |
| Maximum torque | 28.7 N-m |
| Maximum current | 33.7 Arms |
| Rated output power | 2.0 kW |
