DELTA ECMA-C10804S7 ECMA series (ASDA-A2) AC Servo Motor
- Brand
- DELTA
- Model
- ECMA-C10804S7
- GEARWELL SKU
- GWP-000029802
- Category
- Servo Systems
Key specifications
- Model code
- C=220V/3000r/min, 1=20-bit incremental encoder, 08=80mm frame, 04=400W, S=keyway with screw hole, with brake and oil seal, 7=special 14mm shaft
- Rated speed
- 3000 r/min
- Rated torque
- 1.27 N-m
- Maximum speed
- 5000 r/min
- Rated current
- 2.6 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELTA ECMA-C10804S7 ECMA series (ASDA-A2) AC Servo Motor |
|---|---|
| Brand | DELTA |
| Model | ECMA-C10804S7 |
| Category | Servo Systems |
| Model code | C=220V/3000r/min, 1=20-bit incremental encoder, 08=80mm frame, 04=400W, S=keyway with screw hole, with brake and oil seal, 7=special 14mm shaft |
| Rated speed | 3000 r/min |
| Rated torque | 1.27 N-m |
| Maximum speed | 5000 r/min |
| Rated current | 2.6 A |
| Maximum torque | 3.82 N-m |
| Maximum current | 7.8 A |
| Rated output power | 0.4 kW |
