DELTA ECMA-LA1855R3 ECMA series (ASDA-A2) AC Servo Motor
- Brand
- DELTA
- Model
- ECMA-LA1855R3
- GEARWELL SKU
- GWP-000029820
- Category
- Servo Systems
Key specifications
- Model code
- L=400V/1500r/min, A=absolute encoder, 18=180mm, 55=5.5kW, R=keyway with screw hole, no brake, with oil seal, 3 (lineup ECMA-L△1855□3)
- Rated speed
- 1500 r/min
- Rated torque
- 35.0 N-m
- Maximum speed
- 3000 r/min
- Rated current
- 22.37 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELTA ECMA-LA1855R3 ECMA series (ASDA-A2) AC Servo Motor |
|---|---|
| Brand | DELTA |
| Model | ECMA-LA1855R3 |
| Category | Servo Systems |
| Model code | L=400V/1500r/min, A=absolute encoder, 18=180mm, 55=5.5kW, R=keyway with screw hole, no brake, with oil seal, 3 (lineup ECMA-L△1855□3) |
| Rated speed | 1500 r/min |
| Rated torque | 35.0 N-m |
| Maximum speed | 3000 r/min |
| Rated current | 22.37 A |
| Maximum torque | 87.53 N-m |
| Maximum current | 56 A |
| Rated output power | 5.5 kW |
