DELTA ECMA-EA1310RS ECMA series (ASDA-A2) AC Servo Motor
- Brand
- DELTA
- Model
- ECMA-EA1310RS
- GEARWELL SKU
- GWP-000029811
- Category
- Servo Systems
Key specifications
- Model code
- E=220V/2000r/min, A=absolute encoder, 13=130mm, 10=1kW, R=keyway with screw hole, no brake, with oil seal, S=standard shaft
- Rated speed
- 2000 r/min
- Rated torque
- 4.77 N-m
- Maximum speed
- 3000 r/min
- Rated current
- 5.6 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELTA ECMA-EA1310RS ECMA series (ASDA-A2) AC Servo Motor |
|---|---|
| Brand | DELTA |
| Model | ECMA-EA1310RS |
| Category | Servo Systems |
| Model code | E=220V/2000r/min, A=absolute encoder, 13=130mm, 10=1kW, R=keyway with screw hole, no brake, with oil seal, S=standard shaft |
| Rated speed | 2000 r/min |
| Rated torque | 4.77 N-m |
| Maximum speed | 3000 r/min |
| Rated current | 5.6 A |
| Maximum torque | 14.3 N-m |
| Maximum current | 16.8 A |
| Rated output power | 1.0 kW |
