DELTA ECMA-C20804R7 ECMA AC Servo Motor
- Brand
- DELTA
- Model
- ECMA-C20804R7
- GEARWELL SKU
- GWP-000029807
- Category
- Servo Systems
Key specifications
- Max. torque
- 3.82 N-m
- Model code
- C: 220 V / 3,000 rpm; 2: incremental 17-bit encoder; 08: 80 mm; 04: 400 W; R: keyway with fixed screw holes, without brake, with oil seal; 7: specific shaft diameter 14 mm
- Rated power
- 0.4 kW
- Rated speed
- 3000 r/min
- Rated torque
- 1.27 N-m
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELTA ECMA-C20804R7 ECMA AC Servo Motor |
|---|---|
| Brand | DELTA |
| Model | ECMA-C20804R7 |
| Category | Servo Systems |
| Max. torque | 3.82 N-m |
| Model code | C: 220 V / 3,000 rpm; 2: incremental 17-bit encoder; 08: 80 mm; 04: 400 W; R: keyway with fixed screw holes, without brake, with oil seal; 7: specific shaft diameter 14 mm |
| Rated power | 0.4 kW |
| Rated speed | 3000 r/min |
| Rated torque | 1.27 N-m |
| Rated current | 2.60 A |
| Weight (without brake) | 2.1 kg |
| Max. instantaneous current | 7.74 A |
