DELTA ECMA-C10910 ECMA series (ASDA-A2) AC Servo Motor
- Brand
- DELTA
- Model
- ECMA-C10910
- GEARWELL SKU
- GWP-000029805
- Category
- Servo Systems
Key specifications
- Model code
- C=220V/3000r/min, 1=20-bit incremental encoder, 09=86mm frame, 10=1kW, Q=keyway with screw hole, with brake, no oil seal
- Rated speed
- 3000 r/min
- Rated torque
- 3.18 N-m
- Maximum speed
- 3000 r/min
- Rated current
- 4.25 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELTA ECMA-C10910 ECMA series (ASDA-A2) AC Servo Motor |
|---|---|
| Brand | DELTA |
| Model | ECMA-C10910 |
| Category | Servo Systems |
| Model code | C=220V/3000r/min, 1=20-bit incremental encoder, 09=86mm frame, 10=1kW, Q=keyway with screw hole, with brake, no oil seal |
| Rated speed | 3000 r/min |
| Rated torque | 3.18 N-m |
| Maximum speed | 3000 r/min |
| Rated current | 4.25 A |
| Maximum torque | 8.78 N-m |
| Maximum current | 12.37 A |
| Rated output power | 1.0 kW |
