DELTA DOP-110WS HMI Touch Panel
- Brand
- DELTA
- Model
- DOP-110WS
- GEARWELL SKU
- GWP-000006515
- Category
- HMIs & Industrial PCs
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Delta DOP-110WS is a DOP 100 Series Advanced Narrow Frame Type HMI touch panel with a 10.1" TFT LCD at 1024 x 600 pixels (WSVGA) and 65,536 colors. It uses an ARM Cortex-A8 (800MHz) processor with 256 MB flash ROM and 512 MB RAM. Interfaces are one 10/100 Mbps Ethernet port, USB slave and USB host, COM1 RS-232, COM2 RS-232/RS-485 and COM3 RS-422/RS-485, with built-in power isolation. It runs on DC +24V (max. 11 W), has an IP65 / NEMA4 front, and measures 270 x 180.9 x 47.75 mm.
Technical reference
| Product name | DELTA DOP-110WS HMI Touch Panel |
|---|---|
| Brand | DELTA |
| Model | DOP-110WS |
| Category | HMIs & Industrial PCs |
