DELTA ASD-A2-0421-F ASDA-A2 AC Servo Drive
- Brand
- DELTA
- Model
- ASD-A2-0421-F
- GEARWELL SKU
- GWP-000029682
- Category
- Servo Systems
Key specifications
- Model type F
- Network model, DMCNET interface (no analog voltage control/pulse input)
- Phase / voltage
- Three-phase / Single-phase 220VAC
- Input current (1PH)
- 3.22 Arms
- Input current (3PH)
- 1.86 Arms
- Rated output power
- 0.4 kW
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELTA ASD-A2-0421-F ASDA-A2 AC Servo Drive |
|---|---|
| Brand | DELTA |
| Model | ASD-A2-0421-F |
| Category | Servo Systems |
| Model type F | Network model, DMCNET interface (no analog voltage control/pulse input) |
| Phase / voltage | Three-phase / Single-phase 220VAC |
| Input current (1PH) | 3.22 Arms |
| Input current (3PH) | 1.86 Arms |
| Rated output power | 0.4 kW |
| Continuous output current | 2.6 Arms |
| Max. instantaneous output current | 7.80 A |
| Encoder resolution / feedback resolution | Incremental encoder: 20-bit; Absolute encoder: 17-bit |
