Danfoss FC-102P1K5T4E20H2XGCXXXSXXXXAXBXCXXXXDX AC Drive

Product overview

The Danfoss FC-102P1K5T4E20H2XGCXXXSXXXXAXBXCXXXXDX is a VLT® HVAC Drive FC 102 frequency converter for HVAC fans, pumps and compressors, given here with a complete type code. In the type code, P1K5 is 1.5 kW / 2.0 hp, T4 is 3x380-480 V AC, E20 is IP20/chassis, H2 is an RFI filter class A2 (C3), X is no brake IGBT, G is the graphical local control panel LCP 102 and C is a coated PCB class 3C3. The remaining characters select no mains option, standard cable entries, no adaptation, the latest released standard software (SXXX), the standard language package, and no A, B, C0 or C1 options and no DC input (AX, BX, CX, X, DX). At normal overload (110 % for 1 min in 10 min) it delivers 4.1 A continuous and 4.5 A intermittent output current at 3x380-440 V and 3.4 A and 3.7 A at 3x441-480 V; the continuous input current is 3.7 A, the estimated power loss is 62 W and the IP20 enclosure size is A2.
