DANFOSS 130B1238 VLT AHF 005 Advanced Harmonic Filter
- Brand
- DANFOSS
- Model
- 130B1238
- GEARWELL SKU
- GWP-000015769
- Category
- Variable Frequency Drives
Key specifications
- THDi
- < 5% at nominal load
- Enclosure
- X3, IP20 (IP21/NEMA 1 optional)
- Efficiency
- > 98%
- Line voltage
- 380-415 V
- Line frequency
- 50 Hz
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DANFOSS 130B1238 VLT AHF 005 Advanced Harmonic Filter |
|---|---|
| Brand | DANFOSS |
| Model | 130B1238 |
| Category | Variable Frequency Drives |
| THDi | < 5% at nominal load |
| Enclosure | X3, IP20 (IP21/NEMA 1 optional) |
| Efficiency | > 98% |
| Line voltage | 380-415 V |
| Line frequency | 50 Hz |
| Nominal current | 34 A |
| Type designation | AHF-DB-034-400-50-20-A |
| Ambient temperature | 5-45 °C |
| Dimensions (H x W x D) | 592 x 378 x 245 mm |
