CHENYING M21004 NC Oil Level Stainless Float Switch
- Brand
- CHENYING
- Model
- M21004
- GEARWELL SKU
- GWP-000012989
- Category
- Pressure, Flow & Temperature
Key specifications
- Float type
- Galvanized iron float ball
- Order code
- DA01D004
- Contact type
- NC
- Outer thread
- PF1/8
- Max. carry current
- 1.0 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | CHENYING M21004 NC Oil Level Stainless Float Switch |
|---|---|
| Brand | CHENYING |
| Model | M21004 |
| Category | Pressure, Flow & Temperature |
| Float type | Galvanized iron float ball |
| Order code | DA01D004 |
| Contact type | NC |
| Outer thread | PF1/8 |
| Max. carry current | 1.0 A |
| Float ball material | SUS304 |
| Specific gravity (SG) | 0.7 |
| Max. contact capacity | 50 W, SPST |
| Suitable temperature | -20 to 120 °C |
| Max. switching current | 0.5 A |
