BECKHOFF EP6224-2022 EtherCAT Box 4-Channel IO-Link Master
- Brand
- BECKHOFF
- Model
- EP6224-2022
- GEARWELL SKU
- GWP-000007149
- Category
- PLCs & I/O
Key specifications
- Protocol
- EtherCAT
- Bus interface
- 2 x M8 socket, 4-pin, a-coded, shielded
- Nominal voltage
- 24 V DC (-15%/+20%)
- Transmission rate
- 4.8 kbaud, 38.4 kbaud and 230.4 kbaud
- IO-Link interfaces
- 4
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
Beckhoff EP6224-2022 is an IP65/66/67 EtherCAT Box with 4 IO-Link master ports (Class A) on M12 connectors, at 4.8, 38.4 or 230.4 kbaud. Each port supplies up to 1.4 A to its sensor, 4 A in total. Check the full order number, including any suffix, on the module when requesting a quote.
Technical reference
| Product name | BECKHOFF EP6224-2022 EtherCAT Box 4-Channel IO-Link Master |
|---|---|
| Brand | BECKHOFF |
| Model | EP6224-2022 |
| Category | PLCs & I/O |
| Protocol | EtherCAT |
| Bus interface | 2 x M8 socket, 4-pin, a-coded, shielded |
| Nominal voltage | 24 V DC (-15%/+20%) |
| Transmission rate | 4.8 kbaud, 38.4 kbaud and 230.4 kbaud |
| IO-Link interfaces | 4 |
| Connection technology | M12 socket, 5-pin, a-coded |
| IO-Link sensor supply L+ | 24 V DC, 1.4 A per port, ∑ 4.0 A for 4 ports |
| Current consumption from U S | typ. 130 mA + load |
