BECKHOFF C6640-0050 Control Cabinet Industrial PC

Product overview

Beckhoff C6640-0050 is a control cabinet Industrial PC in a stainless steel based housing with an ATX motherboard for 6th/7th generation Intel Celeron, Pentium and Core i3/i5/i7 processors, from the Celeron G3900 (2.8 GHz, 2 cores) up to the Core i7 7700 (3.6 GHz, 4 cores). It has 2 x PCIe x1, 2 x PCIe x4, 1 x PCIe x16 and 2 x PCI slots for plug-in cards up to 210 mm long, 4 GB DDR4 RAM (up to 64 GB), two 100/1000BASE-T Ethernet ports and an on-board SATA RAID 1 controller; the basic configuration has a 1 TB 3½-inch hard disk, 4 x USB 3.0, 2 x DVI, 1 x DisplayPort and 1 x RS232, and all connections face upwards. It runs on 100 to 240 V AC (24 V DC and UPS as options), measures 371 x 336 x 198 mm, weighs 11 kg in the basic configuration and is rated IP20 for 0 to 55 °C. Check the full order number, including any suffix, on the device when requesting a quote.
