BAUMER TE2-1.9.1020.0100.0 TE2 Compact Temperature Transmitter
- Brand
- BAUMER
- Model
- TE2-1.9.1020.0100.0
- GEARWELL SKU
- GWP-000022841
- Category
- Pressure, Flow & Temperature
Key specifications
- Output signal
- 4 … 20 mA, 2-wire (with transmitter)
- Sensor length
- 100 mm
- Article number
- 11138995
- Hygiene approval
- 3-A (74-07); (EC) No 1935/2004
- Process pressure
- -1 … 40 bar
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BAUMER TE2-1.9.1020.0100.0 TE2 Compact Temperature Transmitter |
|---|---|
| Brand | BAUMER |
| Model | TE2-1.9.1020.0100.0 |
| Category | Pressure, Flow & Temperature |
| Output signal | 4 … 20 mA, 2-wire (with transmitter) |
| Sensor length | 100 mm |
| Article number | 11138995 |
| Hygiene approval | 3-A (74-07); (EC) No 1935/2004 |
| Process pressure | -1 … 40 bar |
| Type designation | TE2-1.9.1020.0100.0 |
| Code as collected | [待拆] TE2-1.9.1020.0100.0 |
| Process connection | Tri-Clamp Ø 50.5 (BCID: C04) |
| Process temperature | -50 … 125 °C |
| Thermal response time, T90 | ≤ 8.5 s |
| Degree of protection (EN 60529) | IP 68, with M12-A, 4-pin and appropriate cable |
| Pt100 accuracy class (EN 60751) | 1/1 B ± (0.3 + 0.005 × t)°C |
