BAUMER TE2-1.3.1010.0025.0 TE2 Pt100 Temperature Sensor
- Brand
- BAUMER
- Model
- TE2-1.3.1010.0025.0
- GEARWELL SKU
- GWP-000021888
- Category
- Pressure, Flow & Temperature
Key specifications
- Sensor tip
- Standard response tip, Ø 6 mm
- Cooling neck
- Without
- Sensor element
- Pt100 1/1 B EN 60751, single
- Type designation
- TE2-1.3.1010.0025.0
- Process connection
- G 1/2 A ISO 228-1 (G06)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BAUMER TE2-1.3.1010.0025.0 TE2 Pt100 Temperature Sensor |
|---|---|
| Brand | BAUMER |
| Model | TE2-1.3.1010.0025.0 |
| Category | Pressure, Flow & Temperature |
| Sensor tip | Standard response tip, Ø 6 mm |
| Cooling neck | Without |
| Sensor element | Pt100 1/1 B EN 60751, single |
| Type designation | TE2-1.3.1010.0025.0 |
| Process connection | G 1/2 A ISO 228-1 (G06) |
| Sensor tube length | 25 mm |
| Degree of protection | IP68 with M12-A and appropriate cable |
| Sensor tube material | AISI 316L (1.4404) |
| Electrical connection | M12-A, 4-pin, stainless steel (Pt100 4-wire output) |
| Article number (as listed by seller) | 11054348 |
