BALLUFF BFT 6100-HV003-A02A0C-S4 BFT Temperature Sensor with Display
- Brand
- BALLUFF
- Model
- BFT 6100-HV003-A02A0C-S4
- GEARWELL SKU
- GWP-000022738
- Category
- Pressure, Flow & Temperature
Key specifications
- Display
- 14-segment, red, 4-digit, rotatable by 180°
- Outputs
- PNP switching output; analog 4...20 mA or 0...10 V (3-conductor)
- Evidence
- Balluff manual No. 939082 / 14269536.02 (hosted at automatyka24.pl)
- Connector
- M12x1, 4-pin
- Protection
- IP65/IP67 (when attached)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BALLUFF BFT 6100-HV003-A02A0C-S4 BFT Temperature Sensor with Display |
|---|---|
| Brand | BALLUFF |
| Model | BFT 6100-HV003-A02A0C-S4 |
| Category | Pressure, Flow & Temperature |
| Display | 14-segment, red, 4-digit, rotatable by 180° |
| Outputs | PNP switching output; analog 4...20 mA or 0...10 V (3-conductor) |
| Evidence | Balluff manual No. 939082 / 14269536.02 (hosted at automatyka24.pl) |
| Connector | M12x1, 4-pin |
| Protection | IP65/IP67 (when attached) |
| Probe material | CrNi steel 316Ti, probe diameter 6 mm |
| Supply voltage | 15...35 V DC |
| Measuring range | -20...+80 °C |
| Pressure rating | <= 150 bar |
| Measuring element | Pt1000, 2-conductor, DIN EN 60751 Class A |
