Badger Meter D12Ex-IR GasSens Infrared Gas Transmitter
- Brand
- Badger Meter
- Model
- D12Ex-IR
- GEARWELL SKU
- GWP-000022739
- Category
- Pressure, Flow & Temperature
Key specifications
- Outputs
- Analog signals to remote interfaces; optional relays for local alarming
- Enclosure
- Explosion-proof; certified for use in explosion hazard areas
- Brand note
- Collected as Asaint; official page is Badger Meter (ATI GasSens line)
- Detected gases
- Methane / hydrocarbons (combustible); CO2 with IR CO2 sensor
- CO2 low-range sensor
- 0-1000 ppm min. to 0-5% max. span
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Badger Meter D12Ex-IR GasSens Infrared Gas Transmitter |
|---|---|
| Brand | Badger Meter |
| Model | D12Ex-IR |
| Category | Pressure, Flow & Temperature |
| Outputs | Analog signals to remote interfaces; optional relays for local alarming |
| Enclosure | Explosion-proof; certified for use in explosion hazard areas |
| Brand note | Collected as Asaint; official page is Badger Meter (ATI GasSens line) |
| Detected gases | Methane / hydrocarbons (combustible); CO2 with IR CO2 sensor |
| CO2 low-range sensor | 0-1000 ppm min. to 0-5% max. span |
| CO2 high-range sensor | 0-10% min. to 0-50% max. span |
| Digital communication | Modbus or HART |
