AZBIL HTY7903T6P00 HTY79X3T Insertion Dewpoint Temperature Sensor
- Brand
- AZBIL
- Model
- HTY7903T6P00
- GEARWELL SKU
- GWP-000022474
- Category
- Pressure, Flow & Temperature
Key specifications
- Series
- Insertion Dewpoint Temperature Sensor HTY79X3T (with separate temperature sensor)
- Enclosure
- IP54
- Power supply
- 24 V AC +10/-15 % (50/60 Hz), 24 V DC ±10 %
- Insertion length
- Long
- Dewpoint accuracy
- ±1 °C DP (30-90 %RH, 25 °C)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AZBIL HTY7903T6P00 HTY79X3T Insertion Dewpoint Temperature Sensor |
|---|---|
| Brand | AZBIL |
| Model | HTY7903T6P00 |
| Category | Pressure, Flow & Temperature |
| Series | Insertion Dewpoint Temperature Sensor HTY79X3T (with separate temperature sensor) |
| Enclosure | IP54 |
| Power supply | 24 V AC +10/-15 % (50/60 Hz), 24 V DC ±10 % |
| Insertion length | Long |
| Dewpoint accuracy | ±1 °C DP (30-90 %RH, 25 °C) |
| Temperature range | -20 to 60 °C |
| Temperature output | Pt100 (100 Ω at 0 °C) |
| Temperature accuracy | ±0.3 °C (at -20 to 60 °C) |
| Dewpoint temperature output | 0-10 V (linear to -40 to 60 °C DP) |
