AZBIL CMG250G01010020C CMG Gas Flow Monitor
- Brand
- AZBIL
- Model
- CMG250G01010020C
- GEARWELL SKU
- GWP-000021615
- Category
- Pressure, Flow & Temperature
Key specifications
- Output
- 4–20 mA + event output 2
- Gas type
- Natural gas 13A-45MJ (composition coefficient 1.029)
- Power supply
- 200 V AC (50/60 Hz)
- Display range
- 0.00–16.00 m3/h (normal)
- Code suffix "0C"
- as collected; not listed in the official model-number table (CP-SS-1781E lists 00 / D0)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AZBIL CMG250G01010020C CMG Gas Flow Monitor |
|---|---|
| Brand | AZBIL |
| Model | CMG250G01010020C |
| Category | Pressure, Flow & Temperature |
| Output | 4–20 mA + event output 2 |
| Gas type | Natural gas 13A-45MJ (composition coefficient 1.029) |
| Power supply | 200 V AC (50/60 Hz) |
| Display range | 0.00–16.00 m3/h (normal) |
| Code suffix "0C" | as collected; not listed in the official model-number table (CP-SS-1781E lists 00 / D0) |
| Pressure class | Low pressure, 100 kPa max. |
| Measurement range | 1.00–10.00 m3/h (normal) |
| Protection rating | IP54 |
| Nominal size / connection | 25A, Rc 1 thread |
| Indication accuracy (+10 to +40 °C) | ±4 % RD ±1 digit |
