AZBIL CMG500N150100200 CMG Gas Flow Monitor
- Brand
- AZBIL
- Model
- CMG500N150100200
- GEARWELL SKU
- GWP-000021618
- Category
- Pressure, Flow & Temperature
Key specifications
- Output
- 4–20 mA + event output 2
- Gas type
- Natural gas 13A-46MJ
- Power supply
- 200 V AC (50/60 Hz)
- Display range
- 0.0–170.0 m3/h (normal)
- Pressure class
- Low pressure, 100 kPa max.
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AZBIL CMG500N150100200 CMG Gas Flow Monitor |
|---|---|
| Brand | AZBIL |
| Model | CMG500N150100200 |
| Category | Pressure, Flow & Temperature |
| Output | 4–20 mA + event output 2 |
| Gas type | Natural gas 13A-46MJ |
| Power supply | 200 V AC (50/60 Hz) |
| Display range | 0.0–170.0 m3/h (normal) |
| Pressure class | Low pressure, 100 kPa max. |
| Measurement range | 15.0–150.0 m3/h (normal) |
| Protection rating | IP54 |
| Additional processing | None (00) |
| Nominal size / connection | 50A, Rc 2 thread |
| Indication accuracy (+10 to +40 °C) | ±4 % RD ±1 digit |
