AZBIL C40B5G4AS091D0 SDC40B Digital Indicating Controller
- Brand
- AZBIL
- Model
- C40B5G4AS091D0
- GEARWELL SKU
- GWP-000022451
- Category
- Pressure, Flow & Temperature
Key specifications
- Series
- Digital Indicating Controller SDC40B (C40B)
- Evidence
- Azbil North America hosted Yamatake specification sheet SS1679E-06 (SDC40B)
- Option 1
- 09: 2 auxiliary outputs, 12 digital inputs, 8 digital outputs (3 relays, 5 open collectors)
- Option 2
- 1: No communication interface
- Power supply
- AS: AC power supply (90 to 264 V AC free power supply)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AZBIL C40B5G4AS091D0 SDC40B Digital Indicating Controller |
|---|---|
| Brand | AZBIL |
| Model | C40B5G4AS091D0 |
| Category | Pressure, Flow & Temperature |
| Series | Digital Indicating Controller SDC40B (C40B) |
| Evidence | Azbil North America hosted Yamatake specification sheet SS1679E-06 (SDC40B) |
| Option 1 | 09: 2 auxiliary outputs, 12 digital inputs, 8 digital outputs (3 relays, 5 open collectors) |
| Option 2 | 1: No communication interface |
| Power supply | AS: AC power supply (90 to 264 V AC free power supply) |
| Control output | 5G: current output (4 to 20 mA DC / 0 to 20 mA DC) |
| Function (inputs) | 4: Input 1 multi-range TC/RTD/DC; Input 2: 4-20 mA / 1-5 V DC; Input 3: 1-5 V DC |
| Power consumption | 30 VA max. (AC model) |
| Input sampling cycle | 0.1 to 0.5 s (depends on computation cycle) |
| Additional processing | D0: Inspection certificate provided |
