AZBIL C36TCCUA4200 SDC36 Digital Indicating Controller
- Brand
- AZBIL
- Model
- C36TCCUA4200
- GEARWELL SKU
- GWP-000022449
- Category
- Pressure, Flow & Temperature
Key specifications
- Series
- Single Loop Controller Model C35/C36 (SDC35/SDC36)
- Option 1
- Event relay output: 2 points (independent contact)
- Option 2
- CT inputs: 2 points, digital inputs: 4 points, RS-485 communication
- PV input
- Universal (thermocouple, RTD, DC current, DC voltage)
- Mask size
- 96 x 96 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AZBIL C36TCCUA4200 SDC36 Digital Indicating Controller |
|---|---|
| Brand | AZBIL |
| Model | C36TCCUA4200 |
| Category | Pressure, Flow & Temperature |
| Series | Single Loop Controller Model C35/C36 (SDC35/SDC36) |
| Option 1 | Event relay output: 2 points (independent contact) |
| Option 2 | CT inputs: 2 points, digital inputs: 4 points, RS-485 communication |
| PV input | Universal (thermocouple, RTD, DC current, DC voltage) |
| Mask size | 96 x 96 mm |
| Power supply | 100 to 240 V AC |
| Sampling cycle | 100 ms |
| Control output 1 / 2 | Current output / current output |
| Indication accuracy | ±0.1 % FS ±1 digit |
| Additional processing | None; standards: none |
