AUTONICS MT4N-DV-EN MT4N Digital Panel Meter DC Voltage
- Brand
- AUTONICS
- Model
- MT4N-DV-EN
- GEARWELL SKU
- GWP-000016421
- Category
- Test & Measurement
Key specifications
- Panel size
- W48 x H24 mm
- Measurement
- DC voltage
- Power voltage
- 12-24VDC, 12-24VAC
- Display method
- 4-digit 7-segment LCD
- Sampling cycle
- 50 ms
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS MT4N-DV-EN MT4N Digital Panel Meter DC Voltage |
|---|---|
| Brand | AUTONICS |
| Model | MT4N-DV-EN |
| Category | Test & Measurement |
| Panel size | W48 x H24 mm |
| Measurement | DC voltage |
| Power voltage | 12-24VDC, 12-24VAC |
| Display method | 4-digit 7-segment LCD |
| Sampling cycle | 50 ms |
| Character height | 9 mm |
| Max. display range | -1999 to 9999 |
| Input specification | 0-50V, 0-10V, 0-5V, 0-1V, 0-250mV, 0-50mV |
| Protection structure | IP54 (front part, IEC standard) |
| Main output (comparative value) | Indicator |
