AUTONICS MT4W-AV-4N MT4W Digital Panel Meter AC Voltage
- Brand
- AUTONICS
- Model
- MT4W-AV-4N
- GEARWELL SKU
- GWP-000016424
- Category
- Test & Measurement
Key specifications
- Panel size
- W96 x H48 (DIN) mm
- Measurement
- AC voltage, Frequency
- Power voltage
- 100-240VAC 50/60Hz
- Display method
- 4-digit 7-segment LED
- Sampling cycle
- 16.6 ms
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS MT4W-AV-4N MT4W Digital Panel Meter AC Voltage |
|---|---|
| Brand | AUTONICS |
| Model | MT4W-AV-4N |
| Category | Test & Measurement |
| Panel size | W96 x H48 (DIN) mm |
| Measurement | AC voltage, Frequency |
| Power voltage | 100-240VAC 50/60Hz |
| Display method | 4-digit 7-segment LED |
| Sampling cycle | 16.6 ms |
| Character height | 14.2 mm |
| Max. display range | -1999 to 9999 |
| Input specification | 0-500V, 0-250V, 0-110V, 0-50V, 0-20V, 0-10V, 0-2V, 0-1V |
| Protection structure | IP56 (front part, IEC standard) |
| Main output (comparative value) | Indicator |
