AUTONICS MP5Y-24 MP5Y Series High-Performance Digital Pulse Meter
- Brand
- AUTONICS
- Model
- MP5Y-24
- GEARWELL SKU
- GWP-000016416
- Category
- Test & Measurement
Key specifications
- Measurement
- 16 operation modes: Frequency, Revolutions, Speed, Cycle, Time, Ratio, Density, Error, Length measurement, Interval, Accumulation, Addition/Subtraction, etc.
- Input method
- Voltage input(PNP), No-voltage input(NPN)
- Power voltage
- 24VAC~ 50/60Hz, 24-48VDC
- Display method
- 5-digit 7-segment LED
- Character height
- 14mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS MP5Y-24 MP5Y Series High-Performance Digital Pulse Meter |
|---|---|
| Brand | AUTONICS |
| Model | MP5Y-24 |
| Category | Test & Measurement |
| Measurement | 16 operation modes: Frequency, Revolutions, Speed, Cycle, Time, Ratio, Density, Error, Length measurement, Interval, Accumulation, Addition/Subtraction, etc. |
| Input method | Voltage input(PNP), No-voltage input(NPN) |
| Power voltage | 24VAC~ 50/60Hz, 24-48VDC |
| Display method | 5-digit 7-segment LED |
| Character height | 14mm |
| Max. display range | -19999 to 99999 |
| Protection rating | IP54 (front part, IEC standard) |
| Sub output (display value) | PV transmission (DC0-20mA, DC4-20mA) |
