AUTONICS MP5W-49 MP5W Series High-Performance Digital Pulse Meter
- Brand
- AUTONICS
- Model
- MP5W-49
- GEARWELL SKU
- GWP-000016415
- Category
- Test & Measurement
Key specifications
- Measurement
- 16 operation modes: Frequency, Revolutions, Speed, Cycle, Time, Ratio, Density, Error, Length measurement, Interval, Accumulation, Addition/Subtraction, etc.
- Input method
- Voltage input(PNP), No-voltage input(NPN)
- Power voltage
- 100-240VAC~ 50/60Hz
- Display method
- 5-digit 7-segment LED
- Character height
- 14mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS MP5W-49 MP5W Series High-Performance Digital Pulse Meter |
|---|---|
| Brand | AUTONICS |
| Model | MP5W-49 |
| Category | Test & Measurement |
| Measurement | 16 operation modes: Frequency, Revolutions, Speed, Cycle, Time, Ratio, Density, Error, Length measurement, Interval, Accumulation, Addition/Subtraction, etc. |
| Input method | Voltage input(PNP), No-voltage input(NPN) |
| Power voltage | 100-240VAC~ 50/60Hz |
| Display method | 5-digit 7-segment LED |
| Character height | 14mm |
| Max. display range | -19999 to 99999 |
| Protection rating | IP54 (front part, IEC standard) |
| Sub output (display value) | RS485 communication |
| Main output (comparative value) | PNP open collector (HH, H, GO, L, LL) |
