ASHCROFT T4 20 T05 030 XNH 150/260F T4 Series Temperature Switch
- Brand
- ASHCROFT
- Model
- T4 20 T05 030 XNH 150/260F
- GEARWELL SKU
- GWP-000023128
- Category
- Pressure, Flow & Temperature
Key specifications
- Option
- XNH - stainless steel tagging
- Enclosure
- T4 - watertight, NEMA 3, 4, 4X, 13 and IP66, epoxy coated aluminum
- Bulb length
- 030 - 3 in (remote mount)
- Wetted parts
- Bulb and capillary 316 SS, spiral armor 302 SS
- Switch element
- 20 - narrow deadband AC, 15 A, 125/250 VAC (1 SPDT)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | ASHCROFT T4 20 T05 030 XNH 150/260F T4 Series Temperature Switch |
|---|---|
| Brand | ASHCROFT |
| Model | T4 20 T05 030 XNH 150/260F |
| Category | Pressure, Flow & Temperature |
| Option | XNH - stainless steel tagging |
| Enclosure | T4 - watertight, NEMA 3, 4, 4X, 13 and IP66, epoxy coated aluminum |
| Bulb length | 030 - 3 in (remote mount) |
| Wetted parts | Bulb and capillary 316 SS, spiral armor 302 SS |
| Switch element | 20 - narrow deadband AC, 15 A, 125/250 VAC (1 SPDT) |
| Thermal system | T05 - remote mount, 5 ft capillary |
| Code as collected | T4 20 T05 030 XNH 150° to 260°F |
| Set repeatability | ±1 % of span |
| Temperature range | 150 to 260 °F (65 to 125 °C) |
| Electrical termination | 3/4 NPT female |
