Allen-Bradley 5069-L330ERS2 Compact GuardLogix 5380 3 MB Safety Controller
- Brand
- Allen-Bradley
- Model
- 5069-L330ERS2
- GEARWELL SKU
- GWP-000002313
- Category
- Industrial Automation Parts
Key specifications
- Module (MOD) power
- 18–32 V DC SELV/PELV; 475 mA maximum
- Integrated Motion on EtherNet/IP
- No Integrated Motion support
- Local I/O modules, max
- 31 modules
- Product type
- Compact GuardLogix 5380 SIL 2 controller
- Removable terminal block kit
- 5069-RTB64-SCREW or 5069-RTB64-SPRING; ordered separately
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Allen-Bradley 5069-L330ERS2 is a Compact GuardLogix 5380 SIL 2 safety controller with 3 MB of user memory and 1.5 MB of safety memory, two Ethernet ports for Dual-IP or Linear/DLR operation and a USB programming port. It handles up to 31 local Compact 5000 I/O modules and 60 EtherNet/IP nodes and runs 31 standard tasks plus one safety task. This version has no Integrated Motion; Rockwell reserves that for catalog numbers with M. It is certified for SIL 2 to EN 62061/IEC 61508 and Cat. 3/PL d to EN ISO 13849-1. The controller mounts on a DIN rail, operates at 0…60 °C, ships with a 1784-SD2 2 GB SD card and is programmed in Studio 5000 Logix Designer.
Technical reference
| Product name | Allen-Bradley 5069-L330ERS2 Compact GuardLogix 5380 3 MB Safety Controller |
|---|---|
| Brand | Allen-Bradley |
| Model | 5069-L330ERS2 |
| Category | Industrial Automation Parts |
| Module (MOD) power | 18–32 V DC SELV/PELV; 475 mA maximum |
| Integrated Motion on EtherNet/IP | No Integrated Motion support |
| Local I/O modules, max | 31 modules |
| Product type | Compact GuardLogix 5380 SIL 2 controller |
| Removable terminal block kit | 5069-RTB64-SCREW or 5069-RTB64-SPRING; ordered separately |
| Safety memory | 1.5 MB |
| Safety capability (application-dependent) | Up to SIL 2 / PLd (Category 3) with safety task and safety I/O; specified firmware and application validation required |
| EtherNet/IP network modes | Dual-IP or Linear/DLR |
| EtherNet/IP nodes, max | 60 |
| Built-in Ethernet ports | 2 Ethernet ports; 10/100 Mbps or 1 Gbps; full-duplex only |
| Standard memory | 3 MB |
| USB programming port | USB 2.0 Type B, 12 Mbps; programming, configuration, firmware updates and online edits only |
