Allen-Bradley 5069-IB16K Compact 5000 16-Channel DC Sinking Input Module, Conformal Coated
- Brand
- Allen-Bradley
- Model
- 5069-IB16K
- GEARWELL SKU
- GWP-000003997
- Category
- PLCs & I/O
Key specifications
- Nominal on-state input voltage
- 24 V DC
- MOD power consumption
- 75 mA at 18-32 V DC
- Input delay, off-to-on and on-to-off
- 100 microseconds or less, +/-10 microseconds at 25 C
- Input signal
- DC sinking
- Product type
- Conformal-coated Compact 5000 DC sinking input module
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Allen-Bradley 5069-IB16K is a Compact 5000 16-point conformal-coated sinking input module. Compact 5000 I/O modules work as local I/O in CompactLogix 5380 and Compact GuardLogix 5380 systems and as remote I/O behind a 5069 EtherNet/IP adapter, and Producer/Consumer technology lets several Logix 5000 controllers share their data. Configure it in Studio 5000 Logix Designer and order the field wiring terminal block separately as a 5069-RTB18-SCREW or 5069-RTB18-SPRING.
Technical reference
| Product name | Allen-Bradley 5069-IB16K Compact 5000 16-Channel DC Sinking Input Module, Conformal Coated |
|---|---|
| Brand | Allen-Bradley |
| Model | 5069-IB16K |
| Category | PLCs & I/O |
| Nominal on-state input voltage | 24 V DC |
| MOD power consumption | 75 mA at 18-32 V DC |
| Input delay, off-to-on and on-to-off | 100 microseconds or less, +/-10 microseconds at 25 C |
| Input signal | DC sinking |
| Product type | Conformal-coated Compact 5000 DC sinking input module |
| Manufacturer lifecycle status (2026-10-09) | Active |
| On-state input voltage range | 10-32 V DC |
| Maximum power dissipation | 3.9 W |
| Input channels | 16, one group |
| Product description | 16-channel 12/24 V DC sinking input module, conformal coated |
| Nominal on-state input current | 6 mA at 24 V DC |
