Allen-Bradley 20G11TD710JN0NNNNN PowerFlex 755 600 hp 480 V AC VFD
- Brand
- Allen-Bradley
- Model
- 20G11TD710JN0NNNNN
- GEARWELL SKU
- GWP-000001060
- Category
- Industrial Automation Parts
Key specifications
- Enclosure
- IP00, UL Type Open, without control pod
- Input type
- AC input with precharge and DC terminals
- Product type
- PowerFlex 755 variable-frequency AC drive
- AC input voltage
- 480 V AC
- Normal-duty output current
- 710 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Allen-Bradley 20G11TD710JN0NNNNN is a PowerFlex 755 floor-mount base drive for open frame designs (IP00, UL Open Type without control POD) for the 480 V AC / 650 V DC class, with AC input with precharge and DC terminals. One base drive is rated 765 A and 650 Hp for light duty, 710 A and 600 Hp for normal duty and 545 A and 450 Hp for heavy duty, the equivalent of a frame 8 drive; ordered in a quantity of 2 or 3, the same base drive builds the frame 9 or frame 10 equivalent ratings. This version has filtering with the common mode capacitor jumper installed and no internal dynamic braking transistor. Open frame drives use the same drive units as the standard IP20 and IP54 products, cover applications from 215 kW to 1500 kW (250…2000 Hp) and are installed in an enclosure of your choosing; Rockwell requires a roll-out cart to install frame 8…10 drives. The PowerFlex 755 is Rockwell's 750-Series drive for maximum flexibility and performance up to 2000 Hp and 1500 kW, with a built-in Ethernet port, slot-based option cards, DeviceLogix embedded control and a choice of safety options.
Technical reference
| Product name | Allen-Bradley 20G11TD710JN0NNNNN PowerFlex 755 600 hp 480 V AC VFD |
|---|---|
| Brand | Allen-Bradley |
| Model | 20G11TD710JN0NNNNN |
| Category | Industrial Automation Parts |
| Enclosure | IP00, UL Type Open, without control pod |
| Input type | AC input with precharge and DC terminals |
| Product type | PowerFlex 755 variable-frequency AC drive |
| AC input voltage | 480 V AC |
| Normal-duty output current | 710 A |
| Dynamic braking | No internal braking transistor |
| Heavy-duty motor power | 450 hp |
| Lifecycle status | Active |
| Normal-duty motor power | 600 hp |
| Drive configuration | The Allen-Bradley 20G11TD710JN0NNNNN is a PowerFlex 755 variable-frequency drive for AC motor control. Rated at 600 hp normal duty (450 hp heavy duty), with 710 A continuous normal-duty output. AC input with precharge and DC terminals, rated 480 V AC three-phase input. Enclosure: IP00, UL Type Open, without control pod. Frame 8. No internal braking transistor. EMC filter; common-mode jumper installed by default. Operator interface: No door-mounted HIM. Light-duty motor rating: 650 hp. Standard protection; forced-air cooling. |
