Allen-Bradley 20G14NC170JN0NNNNN AC Drive
- Brand
- Allen-Bradley
- Model
- 20G14NC170JN0NNNNN
- GEARWELL SKU
- GWP-000010855
- Category
- Variable Frequency Drives
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Allen-Bradley 20G14NC170JN0NNNNN is a PowerFlex 755 AC drive for the 400 V AC / 540 V DC class in frame 6, built as an IP00, NEMA/UL Type Open wall-mount chassis with DC input with precharge (common bus). Rockwell rates it at 170 A and 90 kW for normal duty and 140 A and 75 kW for heavy duty. This version has filtering with the common mode capacitor jumper installed and no internal dynamic braking transistor. The PowerFlex 755 is Rockwell's 750-Series drive for maximum flexibility and performance up to 2000 Hp and 1500 kW, with a built-in Ethernet port, slot-based option cards, DeviceLogix embedded control and a choice of safety options.
Technical reference
| Product name | Allen-Bradley 20G14NC170JN0NNNNN AC Drive |
|---|---|
| Brand | Allen-Bradley |
| Model | 20G14NC170JN0NNNNN |
| Category | Variable Frequency Drives |
