Allen-Bradley 1756OF8HK ControlLogix Conformally Coated 8-Point HART Analog Output Module
- Brand
- Allen-Bradley
- Model
- 1756OF8HK
- GEARWELL SKU
- GWP-000000040
- Category
- PLCs & I/O
Key specifications
- Display
- Module Health, In Calibration,Mode
- Isolation
- None between channels (Single,Ended)
- Output signal
- -10 to +10 V, 0-20 mA or 4-20 mA
- Terminal count
- 20-pin
- Special Features
- Supports HART Protocol
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Allen-Bradley 1756-OF8HK is a ControlLogix voltage/current output analog module with HART protocol for the 1756 chassis. It has eight voltage or current outputs (±10V, 0…20 mA, 4…20 mA) with HART communication and 15…16 bit resolution. Field wiring goes through a 1756-TBNH or 1756-TBSH removable terminal block, which is ordered separately. This K version adds conformal coating for harsh, corrosive environments. ControlLogix I/O modules can sit in any slot of a local ControlLogix chassis or in a remote chassis linked over EtherNet/IP or ControlNet, and their input data and output status can be shared by more than one controller.
Technical reference
| Product name | Allen-Bradley 1756OF8HK ControlLogix Conformally Coated 8-Point HART Analog Output Module |
|---|---|
| Brand | Allen-Bradley |
| Model | 1756OF8HK |
| Category | PLCs & I/O |
| Display | Module Health, In Calibration,Mode |
| Isolation | None between channels (Single,Ended) |
| Output signal | -10 to +10 V, 0-20 mA or 4-20 mA |
| Terminal count | 20-pin |
| Special Features | Supports HART Protocol |
| Conformal coating | true |
| Number Of Channels | 8 |
