Allen-Bradley 1746-P4 PLC Module
- Brand
- Allen-Bradley
- Model
- 1746-P4
- GEARWELL SKU
- GWP-000000430
- Category
- PLCs & I/O
Key specifications
- Class
- Power supply units
- Depth
- 145mm, 5.70"
- Power Supply
- Power Supply - Rack Mount,
- Frequency Rating
- 47...63Hz
- Connection Cables
- None required
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Allen-Bradley 1746-P4 is an SLC 500 AC power supply for 85…132/170…250V AC, 47…63 Hz, with the input range set by a jumper. It supplies 10 A at 5V and 2.88 A at 24V to the backplane, plus 1 A at 24V DC for user devices, with the total of all outputs limited to 70 W; inrush current is 45 A max. It is rated for 0…60 °C with no derating.
Technical reference
| Product name | Allen-Bradley 1746-P4 PLC Module |
|---|---|
| Brand | Allen-Bradley |
| Model | 1746-P4 |
| Category | PLCs & I/O |
| Class | Power supply units |
| Depth | 145mm, 5.70" |
| Power Supply | Power Supply - Rack Mount, |
| Frequency Rating | 47...63Hz |
| Connection Cables | None required |
