YOKOGAWA AAM10 CENTUM CS Current/Voltage Input Module
- Brand
- YOKOGAWA
- Model
- AAM10
- GEARWELL SKU
- GWP-000026731
- Category
- PLCs & I/O
Key specifications
- Series
- Also listed for CENTUM CS 3000 RIO as Current/Voltage Input Module (Simplified Type)
- Input signal
- 4 to 20 mA DC (transmitter power supply possible) or 1 to 5 V DC
- Accuracy rating
- Voltage input ±4 mV; current input ±16 µA
- Input resistance
- 250 ohm (current); 1 Mohm (voltage)
- Signal isolation
- Inputs isolated between systems; withstanding voltage 1500 V AC/min
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | YOKOGAWA AAM10 CENTUM CS Current/Voltage Input Module |
|---|---|
| Brand | YOKOGAWA |
| Model | AAM10 |
| Category | PLCs & I/O |
| Series | Also listed for CENTUM CS 3000 RIO as Current/Voltage Input Module (Simplified Type) |
| Input signal | 4 to 20 mA DC (transmitter power supply possible) or 1 to 5 V DC |
| Accuracy rating | Voltage input ±4 mV; current input ±16 µA |
| Input resistance | 250 ohm (current); 1 Mohm (voltage) |
| Signal isolation | Inputs isolated between systems; withstanding voltage 1500 V AC/min |
| Data update period | 50 ms |
| Style (as collected) | S1 |
| Current consumption | 250 mA or less (5.0 V DC) |
| Transmitter power supply | 25.0 to 25.5 V DC |
