YOKOGAWA AAM50-S1 CENTUM CS Current Output Module
- Brand
- YOKOGAWA
- Model
- AAM50-S1
- GEARWELL SKU
- GWP-000026692
- Category
- PLCs & I/O
Key specifications
- Style
- S1 (as collected; GS 33G06K40-01E does not list style codes)
- Output signal
- 4 to 20 mA DC
- Accuracy rating
- +/-48 uA (current output)
- Signal isolation
- Output signals isolated between systems; withstanding voltage 1500 V AC/min
- Data update period
- 20 ms; step response 100 ms
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | YOKOGAWA AAM50-S1 CENTUM CS Current Output Module |
|---|---|
| Brand | YOKOGAWA |
| Model | AAM50-S1 |
| Category | PLCs & I/O |
| Style | S1 (as collected; GS 33G06K40-01E does not list style codes) |
| Output signal | 4 to 20 mA DC |
| Accuracy rating | +/-48 uA (current output) |
| Signal isolation | Output signals isolated between systems; withstanding voltage 1500 V AC/min |
| Data update period | 20 ms; step response 100 ms |
| Current consumption | 250 mA or less (5.0 V DC) |
| Allowable load resistance | 0 to 750 ohm |
